Vermatic cushion-clamp assemblies are a simple, reliable system that reduces shock and vibration caused by fluid surges in pipes, tubes, and hoses used in both mobile and stationary industrial applications.
The cushions are composed of a high impact copolymer with exceptional toughness, low temperature impact resistance, and long life to temperatures of +220º F. The polypropylene remains stable in applications subjected to light acids, solvents, fuels, mineral oils, alcohol, paints, and salt water.

The quality steel hardware can be weld or channel mounted for fast and easy installation. And, because our clamps are used in a range of applications, we make sure they are durable by adding secondary process coatings like zinc, black oxide or yellow dichromate for added protection. For special requirements we can also fabricate both hardware and cushions from other materials, including stainless steel and aluminum.

Stock clamp assemblies are available for tubing sizes from .250 – 6.625 O.D., piping sizes from 1/8P to 6P, and hose sizes from 1/2 to 6.625 inch O.D. If your project requires special customizations contact us today.

100 Series Clamps

  • Weld and Channel Mount
  • Button Fastener
  • Closed End Cushion
  • One or Two Unit Clamp

200 Series Clamps

  • Weld and Channel Mount
  • One Bolt, Button Fastener
  • Closed End Cushion
  • Two to Four Unit Clamp

600 Series Clamps

  • Channel Mount
  • Channel Nut Fastener
  • Closed End Cushion
  • One or Two Unit Clamp

Standard Series Clamps

  • Weld and Channel Mount
  • Post Fastener
  • Open End Cushion
  • One to Six Unit Clamp
